SINUS J

Power Range and Voltage Classes

Voltage Class 2S/T
Single-phase Supply
220÷240 Vac (-5%/+10%)
0.4÷15 kW

Three-phase Supply
200÷240 Vac (-15%/+10%)
0.4÷22 kW

Voltage Class 4T
Three-phase Supply
380÷480 Vac (-15%/+10%)
0.4÷22 kW

Multi-purpose, high-performance compact drive for three-phase asynchronous motors.

– 4 digit 7-segment / 6 key buttons + Built-in potentiometer
– Optional Remote Keypad
– Smart Copier device for parameters and firmware download/upload with switched-off drive
– Conduit Kit for cable entry, NEMA1 protection
– Optional field bus cards: CANopen, Ethernet/IP, Modbus TCP, Profibus-DP
– Input/output three-phase inductors
– Braking resistor
– Toroidal output filters

– Protection degree IP20
– Side-by Side installation (Zero Stack)
– Integrated braking module on all models
– Overload up to 120% for 60 s (Normal Duty)
– Overload up to 150% for 60 s (Heavy Duty)
– Operating temperature without derating: -10 °C up to 50 °C, depending on overload type
– Integrated RS485 serial port, MODBUS RTU communication protocol
– Integrated A2 EMC filter for 4T models
– Standard compliance CE, UL, UKCA, RoHS

– Integrated control methods: V/F, Sensorless Vector Control
– Lifetime Detection (fans)
– Selectable motor auto-tuning: standstill or moving
– Compatible with “REMOTE DRIVE” software for remote control
